Brand Name Diligent ant
Certification RoHS
Origin CN(Origin)
Insulation Material Silica gel
is_customized Yes
Conductor Material Tinned copper
Model Number Heat resistant silicone wire
Conductor Type Stranded
Application RC, battery, electrical equipment
Type Heat resistant, cold resistant
Color
white
black
green
Red
gray
Blue
Yellow
Purple
Brown
Orange
Specification
17 AWG 1 meter
30 AWG 5 meters
24 AWG 5 meters
18 AWG 1 meter
14 AWG 1 meter
16 AWG 1 meter
15 AWG 1 meter
26 AWG 5 meters
12 AWG 1 meter
28 AWG 5 meters
13 AWG 1 meter
20 AWG 1 meter
22 AWG 1 meter
You are welcome to come, if you have any questions, please contact me, I am happy to serve you, thank you. Detailed parameters of all the following specifications Extra soft high temperature silicone wire and cable 12 wire gauge Temperature: -65 degrees to 200 degrees Each copper wire diameter: 0.08mm Core: 680 strands (3.42 square millimeters) Outer diameter: 4.5mm 14 wire gauge Temperature: -65 degrees to 200 degrees Each copper wire diameter: 0.08mm Core: 400 shares(2.07 square millimeters) Outer diameter: 3.5mm 15 wire gauge Temperature: -65 degrees to 200 degrees- Each copper wire diameter: 0.08mm Core: 300 shares(1.5 square millimeters) Outer diameter: 3.2mm 16 AWG Temperature: -65 degrees to 200 degrees- Each copper wire diameter: 0.08mm Core: 252 shares(1.27 square millimeters) Outer diameter: 3.0mm 17AWG Temperature: -65 degrees to 200 degrees- Each copper wire diameter: 0.08mm Core: 210 shares(1.0 square millimeters) Outer diameter: 2.9mm 18 AWG Temperature: -65 degrees to 200 degrees- Each copper wire diameter: 0.08mm Core: 150 shares(0.75 square millimeters) Outer diameter: 2.3mm 20 AWG Temperature: -65 degrees to 200 degrees- Each copper wire diameter: 0.08mm Core: 100 shares(0.5 square millimeters) Outer diameter: 1.80mm 22 AWG Temperature: -65 degrees to 200 degrees- Each copper wire diameter: 0.08mm Grain: 60 shares(0.3 square millimeters) Outer diameter: 1.70mm 24 AWG Temperature: -65 degrees to 200 degrees- Each copper wire diameter: 0.08mm Core: 40 shares(0.2 square millimeters) Outer diameter: 1.60mm 26 AWG Temperature: -65 degrees to 200 degrees- Each copper wire diameter: 0.08mm Core: 30 shares(0.15 square millimeters) Outer diameter: 1.5mm 28 AWG Temperature: -65 degrees to 200 degrees- Each copper wire diameter: 0.08mm Core: 16 shares(0.08 square millimeters) Outer diameter: 1.3mm 30AWG Temperature: -65 degrees to 200 degrees- Each copper wire diameter: 0.08mm Core: 11 shares(0.06 square millimeters) Outer diameter: 0.8mm use: This product is widely used in the connection of electronic products, batteries, aircraft model batteries, model wiring harnesses, electrical equipment and internally connected instrument equipment, lamps and motor wires DIY for home use
